Increased production-input costs and increased competition conditions in almost every sector; it causes the engineering-R&D studies to be put aside. Since the day it was founded, Nükleon continues it is R&D activities in the sector in every field. In this way, it takes the fruits of it is investments in every product it develops. After many products it has brought to the sector, it offers the product called Climatic Test Cabinet to the sector with it is specially developed software.
Thanks to the special devices made according to the inner chamber that can be used in all areas; has developed a technology that enables special solutions and compact designs for large areas or narrow spaces.
The newly developed Climatic Test Cabinet is the most efficient and ergonomic way to ensure that your products can withstand a variety of temperatures during spring, summer, autumn, winter seasonal variations, different climatic zones.
It provides easy operation to the user by digital touch panel, adjustable safety thermostat and fault diagnosis system. Humidity and temperature are controlled by PID Control System with the help of moisture generator and wet and dry thermometers measured according to the psychrometric diagrams.The refrigerant gas and insulation used are environmentally friendly and CFC free.It has been developed to stimulate real climatic conditions by controlling temperature, humidity and nightday light cycles. It is a cabin where stability, artificial aging, storage and shelf life tests can be easily performed, time and illumination programming can be performed to monitor the behavior of the sample placed at constant temperatures in desired ambient conditions, the temperature changes are reported through the audible alarm system and LED display.
The lamps with sufficient power inside the door are protected by heat and moisture resistant glass and provide daylight to the samples. The inner glass door allows samples to be observed without affecting the humidity and temperature values inside the cell. Humidity is supplied by a humidity generator and measured by the humidity sensor inside the cell. Temperature, humidification and cooling are done by proportional-integralderivative control system. Climatic Test Cabinet devices are insulated with high density polyurethane injected.
Intended Use
Quality control, stability, aging, storage, shelf life and research for products manufactured in industries such as electronics and communications, military equipment, automotive and automotive supply industry, aviation, chemistry, plastics, textiles, pharmaceuticals, food, packaging. can be used in quality control laboratories where development tests are conducted.
It can be used in research laboratories in the mechanical engineering, electronic engineering, civil engineering, food engineering and chemical engineering departments of universities.
Accustoming plants to new climatic conditions; it can be used in many different sectors such as plant, tissue, protoplasm and cell culture production, genetic research, seed germination and insect breeding.
Environmentally Optimized Features
It provides ergonomic use with PLC control system which provides the best climate conditions continuously and 4.3 “color touch screen placed on the door. Precise work can be done with the ramp feature that can be programmed as a time for heating and cooling. The products used contain very environmentally friendly products, considering the environment from yesterday to today and from today to tomorrow. Climatic Test Cabinet in order to provide maximum durability and reliability, the most accurate materials are used in internal and external structure. The cell is made of stainless steel and the outer body is made of epoxy painted galvanized steel so as not to be affected by high humidity.
Technical Specifications
• Cell volume (L): 120/250/500/750/1000 liter and optional production.
• Coured touch screen: 4.3” coured touch screen.
• Temperature and reading precision: 0.1°C.
• Temperature fluctuation: ±3°C / max.
• Control system: PID microprocessor control unit/ Special NükleonTM software system.
• Timer/Number of repetition: For all steps 1min-999 hours or time independent working/1- 999 repetition.
• Program memory/Number of steps: 1-20 Memory/ 1-50 Step.
• Non-humid temperature range: -40°C /+150°C.
• Temperature range with humidity: +10°C/+70°C.
• Humidity range: %20 / %98 Rh.
• Humidity fluctuations: ± %7 max.
• Humidity and reading precision: %1 Rh
• Humidity sensor: +200°C durable humidity sensor.
• Water system for humidification: Otomatic water feeding system and manuel water filling system (Pre-distillation system included).
• Heating system: Stick resistance system for humid environment.
• Shelf system: 2 pieces of holed stainless shelves.
• Inner surface: 304 quality stainless steel.
• Inner illumination: Temperature resistant lamp system.
• Inner cell fan system: Stainless propeller fan system.
• Electrical board system: PLC, SSR röle control system.
• Outer surface: Electrostatic powder coated steel.
Nükleon Climatic Test Cabinets have been manufactured taking into consideration the future test requirements in addition to the test standards used today. So you can perform your high performance tests.
Metin Çayır
General Manager
Nükleon Laboratuvar Cihazları
